¹ Cancer biology research center, Tongji Hospital, Tongji Medical College, Huazhong University of Science and Technology, Hubei, P.R. China;

² Department of Oncology, Renmin Hospital, Yunyan Medical College, 23 Chaoyang road Shiyan, Hubei, P.R. China

Corresponding Author: Dr Ding ma. Tel: 86 (27) 83662475, Fax: 86 (27) 83662475, E-mail: dma@tjh.tjmu.edu.cn or dingma424@yahoo.com.

Corresponding Author: Dr. Shixuan Wang. Fax: 86 (27) 83662681; E-mail: sxwang@tjh.tjmu.edu.cn.

Note: Xiaoyan Shi and Ling Xi contributed equally to this work

Running title: VEGF-C and COX-2 may promote the canceration of cervical cancer and that VEGF-C/VEGFR-3 system had a significant association with lymph node metastasis

	ABSTRACT
	INTRODUCTION
	MATERIALS AND METHODS
	RESULTS
	DISCUSSION
	ACKNOWLEDGEMENT
	REFERENCES

	ABSTRACT

  To investigate the roles of VEGF-C, VEGFR-3 and cyclooxygenase-2 (COX-2) in tumor progression and lymph node metastasis. The expression of VEGF-C, VEGFR-3 and COX-2 were examined in 93 cases of surgical speciments of cervical diseases by immunohistochemical staining. The correlation between expression of these factors and tumor aggressiveness was evaluated. The expression levels of VEGF-C and COX-2 were much higher in cervical cancer than in cervical intraepithelial neoplasia (CIN) and in chronic cervicitis. VEGF-C expression correlated with lymph node metastases (P<0.01). Multivariate analysis indicated that lymph vessel density (LVD) was associated with the coexpression of VEGF-C and COX-2. Expression of VEGF-C and VEGFR-3 were both in coincidence with lymph node metastasis. VEGF-C and COX-2 may promote the canceration of cervical cancer and that VEGF-C/ VEGFR-3 system had a significant association with the lymphagiogenesis and lymph node metastasis.

KEY WORDS:    vascular endothelial growth factor-C, vascular endothelial growth factor receptor-3, cyclooxygenase-2, lymphagiogenesis, lymph node metastasis, cervical cancer

	INTRODUCTION

  Cervical cancer is the most common cancer in females worldwide, especially in developing country (1). Lymph node metastasis is an important prognostic factor for cervical cancer patients (2, 3). Recently vascular endothelial growth factor-C (VEGF-C), a novel member of the vascular endothelial growth factor family, has been identified as a major regulator of the development of lymphatic vessels (lymphangiogenesis)(4). Previous reports have shown that overexpression of VEGF-C in primary tumors correlates with increased tendency of tumor cell dissemination to regional lymph nodes in a variety of human cancers including breast, prostate, gastric, colorectal, lung and ovarian carcinomas (5-10).
  The cognate receptor of VEGF-C, vascular endothelial growth factor receptor -3(VEGFR-3/flt -4)was known to mainly express in lymphatic endothelium in adult and therefore was regarded as a special marker of lymphatic endothelium. The density and distribution of lymphatic vessels could be detected by VEGFR-3/flt -4 antibody (11-16). It has been investigated that the binding of VEGF-C to its special receptor flt-4 could induce tyrosine phosphorylation of receptors, activate MAPK via intracellular kinase reaction and finally promote proliferation of lymphatic endothelium and lymphangiogenesis (17, 18).
  Cyclooxygenase (COX)-2, a pleiotropic enzyme that mediates many physiological functions, may promote carcinogenesis, tumor proliferation and metastasis by mediating pathological processes that affect mitogenesis, cellular adhesion and immune surveillance (19-21). Therefore, overexpression of COX-2 has also been considered an indicator of tumor invasiveness and aggressiveness as well as a predictor of metastatic potential in various types of cancers, including uterine cervical cancer (20-23). A significant positive correlation between COX-2 and VEGF-C expression has been observed in several human tumors (24-26). Furthermore, VEGF-C was demonstrated to be one of the major downstream genes of COX-2 and up-regulated by COX-2 through EP1/Src/HER-2/Neu signaling pathway in human lung adenocarcinoma cells. COX-2-specific inhibitors significantly attenuated the endogenous VEGF-C expression level in tumor cells (27). These Studies suggest that COX-2 may be a regulator of VEGF-C expression in malignancies.
  In the present study we investigated the expression of VEGF-C, its receptor VEGFR-3 and cyclooxygenase-2 (COX-2) and their relationship with tumor progression and lymph node metastasis in 93 patients with cervical cancer.

	MATERIALS AND METHODS

Patients and Tissues

  The enrolled specimens in this study were from 93 patients (mean age 41.65 years, range 27-69 years) with informed consent, including 45 cases of invasive cervical carcinoma (5 in Stage Ⅰa, 20 in stageⅠb, 10 in stageⅡa, 10 in stage Ⅱb), 30 cases of cervical intraepithelial neoplasia (CIN) and 18 cases of chronical inflammation undergoing surgical treatment in Tongji Hospital from 2002 to 2006. Diagnosis was established preoperatively by punch biopsy or cone excision and verified by post-operation pathological diagnosis. All tissues were fixed with formalin and paraffin embedding. None of the patients received any radiotherapy or chemotherapy prior to the study. All cervical carcinoma patients were treated with radical hysterectomy and pelvic lymph node dissection. 26 of 45 patients with invasive carcinoma have regional lymph node metastasis.

Reagents

  Polyclonal rabbit anti-VEGF-C (H-190), polyclonal rabbit anti-flt-4 (C-20) was purchased from Santa Cruz Biotechnology (Santa Cruz, Calif.). Rabbit polyclonal antibody specific for human cyclooxygenase-2 (COX-2) was purchased from Cayman Chemical (Ann Arbor, MI, USA).

Immunohistochemistry

  Consecutive 4µm sections of each specimen were immunostained for VEGF-C, VEGFR-3 and COX-2. Immunohistochemical staining was performed by the immunoperoxidase technique. Sections of deparaffinized tissues in xylol were heated for 15 min in a microwave oven in 10 mmol/l citrate buffers (pH 6.0). After cooling for 30 min and washing in PBS, endogenous peroxidase was blocked with 3% H2O2 for 20 min, followed by incubation with PBS containing 10% normal goat serum for 30 min. Then the primary antibodies were incubated at 4°C overnight (The primary antibody dilution of VEGF-C, VEGFR-3 and COX-2 was 1:200, 1:300 and 1:50, respectively), followed by detection by the SP kit (NEW Life Science Products, Inc., Boston, Mass.) according to the manufacturer′s instructions. Alternatively, the detection was performed using a biotinylated anti-rabbit Ig and avidin combined with biotinylated peroxidase complex. Sections were incubated with avidin D and biotin solutions. The color was developed with diaminobenzidine (DAB) supplemented with hydrogen peroxide and counterstaining was performed using hematoxylin. A tissue block of breast cancer with a high microvessel density served as a positive control. Negative controls were done by PBS instead of the primary antibody.
  All slides were investigated by two pathologists who were blinded to the cases to prevent any interindividual classification errors. According to the staining percentage of immunoreactive tumor cells, if the distributions of VEGF-C or COX-2 immunoreactivity no less than 10%, the sample was classified as positively stained. If no cell stained or the staining percentage less than 10%, the sample was classified as negatively stained. If the percentage of VEGF-C immunoreactivity was more than 50%, the slide was defined as a strong positive (+++). Accordingly percentage of VEGF-C immunoreactivity between 30% and 50% was defined as moderate positive (++) and 10%-30% weak positive (+) respectively. VEGFR-3 immunoreactivity in lymphatic endothelium or tumor cells more than 10% was defined as a positive result. Lymph vessel density (LVD) was determined by counting the numbers of VEGFR-3 positive vessels in 5 hot areas and getting the mean value under a low power light microscope (100×). Lymphovascular space involvement in immunostained slides was considered positive if at least one tumor cell cluster was clearly visible in a decorated lymphovascular space(20, 28).

Statistical analyses

  The expression of VEGF-C, VEGFR-3 and COX-2 among different cervical diseases was analyzed using Kruskal-Wallis Test. Correlation among VEGF-C, VEGFR-3 and COX-2 expression was analyzed using the Pearson’s correlation. These analyses were performed utilizing the SPSS 11.0 software. For all tests, P 0.05 was considered statistically.

RESULTS

Expression of VEGF-C, VEGFR-3 and Cox2 in cervical tissues

  The immunohistochemical expression of VEGF-C and Cox2 was observed in the cytoplasm of tumor cells. Of the 93 patients, 9 cases (50%) were positive for VEGF-C in chronic cervicitis, 23 cases (76.6%) positive in cervical intraepithelial neoplasia (CIN) and 40 cases (88.9%) positive in cervical cancer (Table 1). In the chronic cervicitis tissue, moderate VEGF-C immunoreactivity was present in the cytoplasm of stroma cells and a weak immunoreactivity in some smooth muscle cells of blood vessels (data not shown). In the CIN and cervical cancer tissue including 26 patients with lymph node metastases, moderate to strong VEGF-C immunoreactivity was present in the cytoplasm of many cancer cells (Figure 1A).
 Of the 45 cervical cancer patients studied, 17 cases (37.8%) were positive for COX-2 expression in cytoplasm (Figure 1C). 8 cases (26.7%) of 30 CIN tissues expressed COX-2 while none of chronic cervicitis expressed COX-2 (P<0.01) (Table 1). Furthermore the immunoreactivity of COX-2 was associated with that of VEGF-C in the specimens (P<0.01) (Table 1).

  Strong immunoreactivity of VEGFR-3 was detected in the lymphatic endothelium in the stroma adjacent to the tumor nest (Figure 1B). In addition, moderate immunoreactivity of VEGFR-3 was also observed in the cytoplasm and membrane of cervical cancer cells. LVD was significantly different between different cervical diseases (Table 2).

Correlation between expression of VEGF-C, VEGFR-3, COX-2 and LVD and Lymphnode metastasis

  The association between expression of VEGF-C, COX-2, VEGFR-3 and LVD was demonstrated by serial sections in cancer cells. There was a positive relationship between the expression of VEGF-C and VEGFR-3 (P<0.01). The number of VEGFR-3 positive vessels increased with the expression of VEGF-C and COX-2. Meanwhile there were few VEGFR-3 positive vessels in VEGF-C and COX-2 negative tissues. Multivariate analysis indicated that lymph vessel density (LVD) was associated with the coexpression of VEGF-C and COX-2. Expression of VEGF-C and VEGFR-3 was both in coincidence with lymph node metastasis. However, expression of COX-2 was not associated with lymph node metastasis (Table 3).



View larger version : [in a new window] Figure 1: Immunohistochemical staining of VEGF-C, VEGFR-3 and COX-2. A, VEGF-C was stained in the cytoplasm of cervical cancer cells. B, VEGFR-3 expressed in the lymphatic vessels of the stromal adjacent to tumor nest. C, COX-2 was stained in the cytoplasm of cervical cancer cells.

DISCUSSION

  Many cancers metastasize to regional lymph nodes, and a positive nodal status often correlates with a poor prognosis of patients. However, the mechanisms of lymphatic metastasis have not been investigated in detail. Recent studies have demonstrated that the expression of VEGF-C is enhanced in various solid tumors, suggesting the possible contribution of VEGF-C to nodal metastasis, possibly through lymphangiogenesis (28, 29). Number of clinical studies has shown a positive correlation between VEGF-C expression and risk of lymph node metastasis in various cancers. Moreover, the increase in VEGF-C level from primary tumor to metastatic lymph node might be a prognostic indicator (30).
  In the present study, our results showed that VEGF-C expressed principally in the cytoplasm of tumor cells which was consistent with the reports (31-33). In addition, a small amount of VEGF-C was detected in the stroma cells and the smooth muscle cells of blood vessels adjacent to the tumor nest (data not shown). We also observed that the expression level of VEGF-C increased with the progression of cervical intraepithelial neoplasia (CIN) to cervical invasive carcinoma, which suggested that VEGF-C might promote the canceration of cervical cancer.
  Study suggested that cancer cells immerged into lymphatic vessels in early stage and metastases to their draining lymphonode was frequently found in human tissues. Morphologically, the dilated lymphatic vessels with cancer cells immerging often located at the periphery of malignant tissues (34). In the present study the expression of VEGFR-3 was not only detected at the lymphatic endothelium but also at the tumor cells and the capillaries of the stroma adjacent to the tumor nest. The serial sections showed that the expression of VEGFR-3 was detected in VEGF-C positive cancer cells. Meanwhile VEGFR-3 positive vessels were rarely found in the VEGF-C negative tissues. Interestingly, we also observed that there were many expanded lymphatic vessels with several cancer cells inside the areas where VEGF-C and VEGFR-3 strongly expressed. However, we identified functional lymphatic vessels within peritumoral stroma, instead of within tumors, together with previous studies (35-37). A reasonable explanation might be that neoplastic cells grown in a confined space generate mechanic stress which may compress or inhibit the development of lymphatic channels inside the tumor (35).
  Multivariate analysis indicated that the expression of VEGF-C and VEGFR-3 correlated with lymph vessel density (LVD). High peritumoral lymphatic microvessel density (LMVD) and lymphatic infiltration were tightly associated with lymph node metastases as increased lymphatic windows provided more opportunity for cancer cells to invade and metastasize to lymph nodes (35). It was reported that VEGF-C has effects on the lymphovascular endothelium through its autocrine signal network by enhancing the permeability, promoting the migration and proliferation of endothelial cells and thus facilitating malignant cells to enter into lymphatic vessels (28). Taken together we may conclude that expression of VEGF-C was positively related to expression of VEGFR-3 and the concomitance of the VEGF-C/VEGFR-3 system facilitates the lymphatic proliferation and invasion.
  Clinical studies have demonstrated that COX-2 is an independent prognostic indicator in cervical cancer patients (38, 39). Recent reports showed that COX-2 implicated in tumor lymphangiogenesis through an upregulation of VEGF-C expression (11). In our study COX-2 was positively detected in 17 (37.8%) cervical cancer patients, which was consistent with previous reports (28). Statistical analysis manifested that COX-2 expression level was related to that of VEGF-C. Moreover, the coexpression of VEGF-C and COX-2 correlated with lymph vessel density (LVD) of the stroma adjacent to the tumor nest. However, there was no significant correlation between COX-2 immunoreactivity and the expression level of VEGFR-3 as well as lymph node metastasis.
  In conclusion, our results indicate that VEGF-C and COX-2 may promote the canceration of cervical cancer and that VEGF-C/ VEGFR-3 system have a significant association with the lymphagiogenesis and lymph node metastasis. Therefore, determination of VEGF-C in biopsy specimens may be useful as a predictor of pelvic lymph node metastasis. COX-2 plays an important role in the lymphatic proliferation and spread through the VEGF-C mediated lymphangiogenic pathway in cervical cancer. VEGF-C/VEGFR-3 could be a potential therapeutic target for cervical cancer.

	ACKNOWLEDGEMENT

  Grant support: National Science Foundation of China (No. 30672227, 30600667, 30500596, 30370657) and the "973" Program (2002CB513100).

	REFERENCES

1. Recio FO, Sahai Srivastava BI, Wong C, Hempling RE, et al. The clinical value of digene hybrid capture HPV DNA testing in a referral-based population with abnormal pap smears. Eur J Gynaecol Oncol. 1998; 19:203-8.
2. Birner P, Obermair A, Schindl M, Kowalski H, et al. Selective immunohistochemical staining of blood and lymphatic vessels reveals independent prognostic influence of blood and lymphatic vessel invasion in early-stage cervical cancer. Clin Cancer Res. 2001; 7:93-7.
3. Birner P, Schindl M, Obermair A, Breitenecker G,. Lymphatic microvessel density as a novel prognostic factor in early-stage invasive cervical cancer. Int J Cancer. 2001; 95:29-33.
4. Joukov V, Pajusola K, Kaipainen A, et al. A novel vascular endothelial growth factor, VEGF-C, is a ligand for the Flt4 (VEGFR-3) and KDR (VEGFR-2) receptor tyrosine kinases. EMBO J. 1996; 15:290-98.
5. Skobe M, Hawighorst T, Jackson DG, et al. Induction of tumor lymphangiogenesis by VEGF-C promotes breast cancer metastasis. Nat Med. 2001; 7:192-8.
6. Tsurusaki T, Kanda S, Sakai H, et al. Vascular endothelial growth factor-C expression in human prostatic carcinoma and its relationship to lymph node metastasis. Br J Cancer. 1999; 80:309-13.
7. Yonemura Y, Endo Y, Fujita H, et al. Role of vascular endothelial growth factor C expression in the development of lymph node metastasis in gastric cancer. Clin Cancer Res. 1999; 5:1823-9.
8. Akagi K, Ikeda Y, Miyazaki M, et al. Vascular endothelial growth factor-C (VEGF-C) expression in human colorectal cancer tissues. Br J Cancer. 2000; 83:887-91.
9. Niki T, Iba S, Tokunou M, Yamada T, et al. Expression of vascular endothelial growth factors A, B, C, and D and their relationships to lymph node status in lung adenocarcinoma. Clin Cancer Res. 2000; 6:2431–2439.
10. Ueda M, Hung YC, Terai Y, et al. Vascular endothelial growth factor-C expression and invasive phenotype in ovarian carcinomas. Clin Cancer Res. 2005; 11:3225-32.
11. Pajusola K, Aprelikova O, Korhonen J, et al. FLT4 receptor tyrosine kinase contains seven immunoglobulin-like loops and is expressed in multiple human tissues and cell lines. Cancer Res. 1992; 52:5738-43.
12. Lymboussaki A, Partanen TA, Olofsson B, et al. Expression of the vascular endothelial growth factor C receptor VEGFR-3 in lymphatic endothelium of the skin and in vascular tumors. Am J Pathol. 1998; 153:395-403.
13. Hamrah P, Chen L, Zhang QandDana MR. Novel expression of vascular endothelial growth factor receptor (VEGFR)-3 and VEGF-C on corneal dendritic cells. Am J Pathol. 2003; 163:57-68.
14. Clarijs R, Schalkwijk L, Hofmann UB, Ruiter DJandde Waal RM. Induction of vascular endothelial growth factor receptor-3 expression on tumor microvasculature as a new progression marker in human cutaneous melanoma. Cancer Res. 2002; 62:7059-65.
15. Jussila L, Valtola R, Partanen TA, et al. Lymphatic endothelium and Kaposi's sarcoma spindle cells detected by antibodies against the vascular endothelial growth factor receptor-3. Cancer Res. 1998; 58:1599-604.
16. Kaipainen A, Korhonen J, Mustonen T, et al. Expression of the fms-like tyrosine kinase 4 gene becomes restricted to lymphatic endothelium during development. Proc Natl Acad Sci U S A. 1995; 92:3566-70.
17. Kubo H, Cao R, Brakenhielm E, Makinen T, et al. Blockade of vascular endothelial growth factor receptor-3 signaling inhibits fibroblast growth factor-2-induced lymphangiogenesis in mouse cornea. Proc Natl Acad Sci U S A. 2002; 99:8868-73.
18. Dias S, Choy M, Alitalo KandRafii S. Vascular endothelial growth factor (VEGF)-C signaling through FLT-4 (VEGFR-3) mediates leukemic cell proliferation, survival, and resistance to chemotherapy. Blood. 2002; 99:2179-84.
19. Smith WL, DeWitt DLandGaravito RM. Cyclooxygenases: structural, cellular, and molecular biology. Annu Rev Biochem. 2000; 69:145-82.
20. Williams CS, Tsujii M, Reese J, Dey SKandDuBois RN. Host cyclooxygenase-2 modulates carcinoma growth. J Clin Invest. 2000; 105:1589-94.
21. Tsujii MandDuBois RN. Alterations in cellular adhesion and apoptosis in epithelial cells overexpressing prostaglandin endoperoxide synthase 2. Cell. 1995; 83:493-501.
22. Ryu HS, Chang KH, Yang HW, Kim MS, et al. High cyclooxygenase-2 expression in stage IB cervical cancer with lymph node metastasis or parametrial invasion. Gynecol Oncol. 2000; 76:320-5.
23. Gaffney DK, Holden J, Davis M, Zempolich K, et al. Elevated cyclooxygenase-2 expression correlates with diminished survival in carcinoma of the cervix treated with radiotherapy. Int J Radiat Oncol Biol Phys. 2001; 49:1213-7.
24. Byeon JS, Jung HY, Lee YJ, et al. Clinicopathological significance of vascular endothelial growth factor-C and cyclooxygenase-2 in esophageal squamous cell carcinoma. J Gastroenterol Hepatol. 2004; 19:648-54.
25. Su JL, Shih JY, Yen ML, et al. Cyclooxygenase-2 induces EP1- and HER-2/Neu-dependent vascular endothelial growth factor-C up-regulation: a novel mechanism of lymphangiogenesis in lung adenocarcinoma. Cancer Res. 2004; 64:554-64.
26. Kyzas PA, Stefanou DandAgnantis NJ. COX-2 expression correlates with VEGF-C and lymph node metastases in patients with head and neck squamous cell carcinoma. Mod Pathol. 2005; 18:153-60.
27. Oshima M, Murai N, Kargman S, et al. Chemoprevention of intestinal polyposis in the Apcdelta716 mouse by rofecoxib, a specific cyclooxygenase-2 inhibitor. Cancer Res. 2001; 61:1733–1740.
28. Ristimaki A, Narko K, Enholm B, Joukov VandAlitalo K. Proinflammatory cytokines regulate expression of the lymphatic endothelial mitogen vascular endothelial growth factor-C. J Biol Chem. 1998; 273:8413-8.
29. Nisato RE, Tille JCandPepper MS. Lymphangiogenesis and tumor metastasis. Thromb Haemost. 2003; 90:591-7.
30. Fujimoto J, Toyoki H, Sato E, Sakaguchi HandTamaya T. Clinical implication of expression of vascular endothelial growth factor-C in metastatic lymph nodes of uterine cervical cancers. Br J Cancer. 2004; 91:466-9.
31. Salven P, Lymboussaki A, Heikkila P, et al. Vascular endothelial growth factors VEGF-B and VEGF-C are expressed in human tumors. Am J Pathol. 1998; 153:103-8.
32. Amioka T, Kitadai Y, Tanaka S, et al. Vascular endothelial growth factor-C expression predicts lymph node metastasis of human gastric carcinomas invading the submucosa. Eur J Cancer. 2002; 38:1413-9.
33. Furudoi A, Tanaka S, Haruma K, et al. Clinical significance of vascular endothelial growth factor C expression and angiogenesis at the deepest invasive site of advanced colorectal carcinoma. Oncology. 2002; 62:157-66.
34. Kitamura K, Yamaguchi T, Taniguchi H, Hagiwara A, et al. Analysis of lymph node metastasis in early gastric cancer: rationale of limited surgery. J Surg Oncol. 1997; 64:42-7.
35. Schoppmann SF, Birner P, Studer PandBreiteneder-Geleff S. Lymphatic microvessel density and lymphovascular invasion assessed by anti-podoplanin immunostaining in human breast cancer. Anticancer Res. 2001; 21:2351-5.
36. Leu AJ, Berk DA, Lymboussaki A, Alitalo KandJain RK. Absence of functional lymphatics within a murine sarcoma: a molecular and functional evaluation. Cancer Res. 2000; 60:4324-7.
37. Isaka N, Padera TP, Hagendoorn J, Fukumura DandJain RK. Peritumor lymphatics induced by vascular endothelial growth factor-C exhibit abnormal function. Cancer Res. 2004; 64:4400-4.
38. Kim YB, Kim GE, Cho NH, et al. Overexpression of cyclooxygenase-2 is associated with a poor prognosis in patients with squamous cell carcinoma of the uterine cervix treated with radiation and concurrent chemotherapy. Cancer. 2002; 95:531-9.
39. Kim YB, Kim GE, Pyo HR, et al. Differential cyclooxygenase-2 expression in squamous cell carcinoma and adenocarcinoma of the uterine cervix. Int J Radiat Oncol Biol Phys. 2004; 60:822-9.
